	WG to Coaxial Adapter - Endlaunch

商品名稱：WG to Coaxial Adapter - Endlaunch

商品編號：WG to Coaxial Adapter - Endlaunch

產品說明：

Vector Telecom為全球市場提供微波波導零件和組件，同軸組件和天線。
Vector Telecom由微波和毫米波實驗室，天線實驗室，微波和電子元件工廠組成。實驗室配備了高達110 GHz的先進微波測量設備。

Download WG to Coaxial Adapter - Endlaunch型錄下載

WG to Coaxial Adapter - End launch Product Range
MODEL NO	FREQ RANGE	VSWR	WG TYPE (IEC/EIA)	FLANGE TYPE	CONNECTOR	MATERIAL
	(GHz)	Max
VT3WECANKPA	0.32-0.49	1.25	R3/WR2300	FDP/FDM	N	ALL
VT4WECANKPA	0.35-0.53	1.25	R4/WR2100	FDP/FDM	N	ALL
VT5WECANKPA	0.41-0.62	1.25	R5/WR1800	FDP/FDM	N	ALL
VT6WECANKPA	0.49-0.75	1.25	R6/WR1500	FDP/FDM	N	ALL
VT8WECANKPA	0.64-0.98	1.25	R8/WR1150	FDP/FDM	N	ALL
VT9WECANKPA	0.75-1.15	1.25	R9/WR975	FDP/FDM	N	ALL
VT12WECANKPA	0.96-1.46	1.25	R12/WR770	FDP/FDM	N	ALL
VT14WECANKPA	1.13-1.73	1.25	R14/WR650	FDP/FDM	N	ALL
VT18WECANKPA	1.45-2.20	1.25	R18/WR510	FDP/FDM	N	ALL
VT22WECANKPA	1.72-2.61	1.25	R22/WR430	FDP/FDM	N	Al/Cu
VT26WECANKPA	2.17-3.30	1.25	R26/WR340	FDP/FDM	N	Al/Cu
VT32WECANKPA	2.60-3.95	1.25	R32/WR284	FDP/FDM	N	Al/Cu
VT40WECANKPA	3.22-4.90	1.25	R40/WR229	FDP/FDM	N	Al/Cu
VT48WECANKPA	3.94-5.99	1.25	R48/WR187	FDP/FDM	N	Al/Cu
VT48WECASKPA	3.94-5.99	1.25	R48/WR187	FDP/FDM	SMA	Al/Cu
VT58WECANKPA	4.64-7.05	1.25	R58/WR159	FDP/FDM	N	Al/Cu
VT58WECASKPA	4.64-7.05	1.25	R58/WR159	FDP/FDM	SMA	Al/Cu
VT70WECANKPC	5.38-8.17	1.25	R70/WR137	FDP/FDM	N	Al/Cu
VT70WECASKPC	5.38-8.17	1.25	R70/WR137	FDP/FDM	SMA	Al/Cu
VT84WECANKPC	6.57-9.99	1.25	R84/WR112	FBP/FBM/FBE	N	Al/Cu
VT84WECASKPC	6.57-9.99	1.25	R84/WR112	FBP/FBM/FBE	SMA	Al/Cu
VT100WECANKPC	8.20-12.40	1.25	R100/WR90	FBP/FBM/FBE	N	Al/Cu
VT100WECASKPC	8.20-12.40	1.25	R100/WR90	FBP/FBM/FBE	SMA	Al/Cu
VT120WECANKPC	9.84-15.0	1.25	R120/WR75	FBP/FBM/FBE	N	Al/Cu
VT120WECASKPC	9.84-15.0	1.25	R120/WR75	FBP/FBM/FBE	SMA	Al/Cu
VT140WECANKPC	11.9-18.0	1.25	R140/WR62	FBP/FBM/FBE	N	Al/Cu
VT140WECASKPC	11.9-18.0	1.25	R140/WR62	FBP/FBM/FBE	SMA	Al/Cu
VT180WECASKPC	14.5-22.0	1.25	R180/WR51	FBP/FBM/FBE	SMA	Al/Cu
VT220WECASKPC	17.6-26.0	1.25	R220/WR42	FBP/FBM/FBE	SMA	Al/Cu
VT220WECA2.92KPC	17.6-26.7	1.25	R220/WR42	FBP/FBM/FBE	2.92mm	Al/Cu
VT220WECA2.4KPC	17.6-26.7	1.25	R220/WR42	FBP/FBM/FBE	2.4mm	Al/Cu
VT260WECA2.92KPC	21.7-33.0	1.25	R260/WR34	FBP/FBM/FBE	2.92mm	Al/Cu
VT260WECA2.4KPC	21.7-33.0	1.25	R260/WR34	FBP/FBM/FBE	2.4mm	Al/Cu
VT320WECA2.92KPC	26.5-40.0	1.25	R320/WR28	FBP/FBM/FBE	2.92mm	Al/Cu
VT320WECA2.4KPC	26.5-40.0	1.25	R320/WR28	FBP/FBM/FBE	2.4mm	Al/Cu
VT400WECA2.4KPC	33.0-50.0	1.5	R400/WR22	FUGP	2.4mm	Cu
VT500WECA2.4KPC	40.0-50.0	2	R500/WR19	FUGP	2.4mm	Cu
VT500WECA1.85KPC	40.0-50.0	2	R500/WR19	FUGP	1.85mm	Cu
VT620WECA1.85KPC	55.0-65.0	2	R620/WR15	FUGP	1.85mm	Cu
VT740WECA1.0KPC	66.0-86.0	2	R740/WR12	FUGP	1.0mm	Cu
VT900WECA1.0KPC	90.0-100.0	2	R900/WR10	FUGP	1.0mm	Cu
VT260WECASKPC	21.7-33.0	1.5	R260/WR34	FBP/FBM/FBE	SMA	Al/Cu
VT320WECASKPC	26.3-40.0	1.5	R320/WR28	FBP/FBM/FBE	SMA	Al/Cu
